Nucleic Acid Detection Station Container Room

1. Introduction of temporary nucleic acid sampling sites

In order to better protect the safety of sampling personnel and provide a comfortable working environment, our company has designed a mobile temporary nucleic acid sampling point, which can provide a safe sampling space for testing personnel.

2. Performance characteristics of temporary nucleic acid sampling points

1) Ultraviolet light sterilization can be timed to realize automatic disinfection when people walk.

2) The nucleic acid detection booth is equipped with a primary filter device and an anti-virus high-efficiency air filter system.

3) The universal caster has its own brake, which is convenient for moving and parking.

4) The positive pressure design of the cavity prevents external bacteria from flowing into the cavity.

5) Air supply volume inside the silo body≧900m3/h

6) The cavity is controlled by constant temperature, with dual-system air conditioners.

7) Equipped with transfer window (ultraviolet sterilization, mechanical interlock), the size can be customized.

8) Double-station operation, more convenient and user-friendly.

9) Intelligent touch screen control, friendly interface, convenient and simple operation.

10) Comes with a non-contact infrared human body temperature measurement function, intelligent voice broadcast, convenient and fast temperature measurement. (optional)

3. Technical Parameters of Temporary Nucleic Acid Sampling Points

Case size (external) 2100mm*1400mm*2800mm (customized)

Case size (internal) 2000mm*1300mm*2000mm (customized)

Chassis material high-quality insulation board

Observation window material: Acrylic (plexiglass)

Sterilization system UV ultraviolet lamp sterilization Sterilization time: 30 minutes to 60 minutes is appropriate

Air supply system FLJ power frequency centrifugal blower

Filter element Primary filtration: dust-proof sponge pad, advanced filtration: H14 filter

Monitoring Internal air pressure display (positive pressure 0-30PA), internal temperature display

Insulation system The warehouse body is made of high-quality insulation board

Intercom system Two-way window intercom system

Lighting system LED lighting

Air Conditioning System Split Air Conditioner (1 HP)

4. Workflow of Temporary Nucleic Acid Sampling Sites

1. When sampling, turn on the positive pressure filter switch to run the positive pressure system of the isolation chamber, and adjust the temperature in the cabin through the air conditioner thermostat;

2. The inspected personnel deliver the equipment to the sampling personnel's sleeves according to the instructions;

3. The inspected person points the forehead to the temperature probe, and then goes to the sampling window for sampling after the body temperature is normal;

4. The sampling personnel in the cabin take the throat swab sampling of the inspected person through the glove operation port, and put the throat swab cotton swab into the sampling tube after sampling;

5. The sample registration and sample finishing personnel in the cabin wipe the surface of the sampling tube introduced by the inspected person, paste the code, and register it and put it into the biological sample transfer box;

6. After the sample storage in the biological sample transfer box reaches a certain amount, the sample registration and sample finishing personnel in the cabin will pass it to the sample transfer personnel outside the cabin;

7. After the sampling is over, after the personnel are withdrawn, turn on the ultraviolet light to sterilize the isolation chamber.

Nucleic Acid Detection Station Container Room pictures:
